This Sandbox environment features a pre-configured network topology designed to showcase the diverse capabilities of the Cisco Catalyst SD-WAN solution. The incorporated set of components within the lab topology includes Controllers and IOS-XE WAN Edges (Catalyst 8000V), all running on 20.18.1/17.18.01a code.

This lab is the Cisco ACI Fundamentals Lab Part 1, and after completion, the student can launch Cisco ACI Fundamentals Lab Part 2 to complete the entire lab. The lab uses the ACI virtual simulator based on ACI Version 6.1(3f), emulating an APIC, 2 leafs, and a spine. Part 2 uses a shared physical ACI fabric to complete the policy and verify data plane connectivity. The ACI Virtual Simulator was needed to demo the building of the ACI fabric from scratch, bootstrapping the APIC, adding the spine and leafs, fabric discovery, and completing VMM integration. Since the Cisco ACI Fundamentals Lab, Part 2 is a shared on-demand environment, to decouple the APIC build process from the APIC policy creation. Due to limitations, the virtual ACI fabric is a control plane-only simulator, and no data plane testing (Ping, SSH) can get done for validation. Cisco ACI Fundamentals Lab Part 2 uses a Tenant inside of a physical ACI, and data plane functionality can get tested ( Ping, SSH)

This lab is a continuation of the Cisco ACI Fundamentals Lab Part 1 to allow students to explore the basics of ACI Constructs, building an Application Profile, EPGs and Bridge domains, Policy Filters, and Contracts. The students then connect the ACI fabric to external layers 2 and 3 devices. The lab then finishes with ACI micro-segmentation inside an EPG to show a zero-trust model. Unlike Cisco ACI Fundamentals Lab Part 1, which uses a simulator due to resource sharing with other students, this lab uses the latest ACI hardware and allows the student to test real-world data plane connectivity inside and outside the fabric.
